SPECIFICATIONS
AC Output Frequency: 50Hz/60Hz ±2Hz
AC Output Socket: Universal Socket
AC Output Voltage: 220V/110V±15%
Application: Solar Power Storage
Battery Capacity: 12.8V 76.8Wh
Battery Type: LiFePO4
Brand Name: GaiaRay
Certification: CE,FCC,RoHS
Charging Interface: DC5521
DC Output Voltage: USB 18W PD 20W
Display screen: Yes
Feature 1: portable power station
Feature 2: Camping backup power supply
Feature 3: 100W power bank
Feature 4: Fast charging power station
Hign-concerned Chemical: None
Model Number: Portable Power Station
Nominal Capacity: 24000mAh
Output Waveform: Modified Sine Wave
Rated Power: 100W
Set Type: Charger Sets
Size: D*W*H(mm) 253*84*214
Solar Panel Specifications: 16V 12W
Type: LiFePO4
Specification:
|
Rated Power |
100W |
|
Output Waveform |
Modified Sine Wave |
|
AC Output Voltage |
220V/110V±15% |
|
AC Output Frequency |
50Hz/60Hz ±2Hz |
|
Conversion Efficiency |
Maximum Value>90% |
|
Charging Interface |
External Charger Port and Solar Panel Charging Port DC5521*1 (Built in solar intelligent controller) |
|
AC Output Socket |
Universal Socket |
|
DC Output Voltage |
1 USB output QC18W; 1 PD output maximum 20W; |
|
LED Light States |
LED high beam, low beam, high brightness, half light, flashing, LED light off 6 states |
|
Battery Type |
LiFePO4 |
|
Battery Capacity |
12.8V 76.8Wh |
|
Comes With Solar Panel Specifications |
16V 12W |
|
External Solar Panel |
15-20V maximum 20W (optional) |
|
AC Charger Specifications |
15V1A |
|
AC Charger Charging Time |
After full discharge, battery capacity reaches 80% after 6 hours of charging |
|
LCD Display |
Battery capacity, battery voltage, charging status, discharge status |
|
Heat Dissipation |
Automatic cooling |
|
Protective Function |
Low voltage, overvoltage, overload, overtemperature, overcurrent short circuit |
|
Operating Environment Temperature |
–10～40℃ |
|
Operating Environment Humidity |
10～85% |
|
Storage Environment Humidity |
5～90% |
|
Net Weight(kg) |
≈1.76kg |
|
Product Size D*W*H(mm) |
253*84*214 |
Product Features：
1. Large Capacity & Versatile Use: With a substantial 24000mAh capacity, the portable solar power station caters to a wide array of situations, from outdoor camping and self-driving tours to fulfilling household emergency needs during power outages. Stay powered up anywhere, anytime.
2. High Quality Lithium Iron Phosphate Battery: The power generator is equipped with a Lithium Iron Phosphate battery that guarantees over 2000+ charge cycles. This high-quality power battery pack ensures a longer lifespan and safer use.
3. Compact and Powerful: Improved over other products on the market, the outdoor camping power bank boasts a smaller volume and lighter weight while maintaining powerful functionality. It can power a variety of electronic devices, making it a convenient and reliable choice for outdoor use.
4. LED Lighting: The outdoor power supply features LED lighting with six modes: LED high beam, low beam, high brightness, half light, flashing, LED light off 6 states
5. Diverse Output:1 USB output QC18W; 1 PD output maximum 20W; 1 AC universal socket; 1 DC 12V output
6. Safe and Efficient: The portable outdoor generator prides itself on safety and efficiency. It provides fast charging and includes multiple safety protections, ensuring reliability and durability for outdoor use.
